GNWT-01 - Washer

Name: GNWT-01 - Washer
Brand: Gecko Fastener GmbH
SKU: GNWT-01
Availability: InStock

Brand: Gecko Fastener GmbH Preis auf Anfrage

Material: NYLON 6
Colour: NATURAL OTHER MATERIALS AND THICKNESSES AVAILABLE ON REQUEST

Add to watchlist

Note

Please contact us for small quantities, free samples and further technical details.

Description
Product Details

When used with screws, the NWT series offers locking, anti-loosening protection and a stable torque, as well as protection against damage to the locked product.

Catalogue No.	Item No.	A	B	C	Packaging unit
GNWT-01	23821900	0.5	Ø4.5	Ø2.1	5000
GNWT-02	23821901	0.5	Ø4.5	Ø2.6	5000
GNWT-03	23821902	0.5	Ø4.6	Ø2.5	5000
GNWT-04	23821903	0.5	Ø4.7	Ø2.6	5000
GNWT-05	23821904	0.5	Ø5.0	Ø2.2	5000
GNWT-06	23821905	0.5	Ø5.0	Ø2.5	5000
GNWT-07	23821906	0.5	Ø5.0	Ø2.6	5000
GNWT-08	23821907	0.5	Ø5.0	Ø3.0	5000
GNWT-09	23821908	0.5	Ø5.0	Ø3.1	5000
GNWT-10	23821909	0.5	Ø5.0	Ø3.2	5000
GNWT-11	23821910	0.5	Ø5.0	Ø3.5	5000
GNWT-12	23821911	0.5	Ø5.6	Ø3.1	5000
GNWT-13	23821912	0.5	Ø5.6	Ø4.8	5000
GNWT-14	23821913	0.5	Ø6.0	Ø2.1	5000
GNWT-15	23821914	0.5	Ø6.0	Ø3.1	5000
GNWT-16	23821915	0.5	Ø6.0	Ø3.2	5000
GNWT-17	23821916	0.5	Ø6.0	Ø3.6	5000
GNWT-18	23821917	0.5	Ø6.0	Ø4.1	5000
GNWT-19	23821918	0.5	Ø6.0	Ø4.3	5000
GNWT-21	23821919	0.5	Ø6.5	Ø2.98	5000
GNWT-22	23821920	0.5	Ø6.5	Ø3.5	5000
GNWT-23	23821921	0.5	Ø6.5	Ø4.1	5000
GNWT-24	23821922	0.5	Ø7.0	Ø2.5	5000
GNWT-25	23821923	0.5	Ø7.0	Ø4.2	5000
GNWT-26	23821924	0.5	Ø7.0	Ø5.1	5000
GNWT-27	23821925	0.5	Ø7.0	Ø3.1	5000
GNWT-28	23821926	0.5	Ø7.5	Ø4.8	5000
GNWT-29	23821927	0.5	Ø7.8	Ø3.2	5000
GNWT-30	23821928	0.5	Ø8.0	Ø3.1	5000
GNWT-31	23821929	0.5	Ø8.0	Ø4.1	5000
GNWT-32	23821930	0.5	Ø8.0	Ø5.0	5000
GNWT-33	23821931	0.5	Ø8.0	Ø5.1	5000
GNWT-34	23821932	0.5	Ø8.0	Ø6.0	5000
GNWT-36	23821933	0.5	Ø8.8	Ø4.0	5000
GNWT-37	23821934	0.5	Ø8.8	Ø5.2	5000
GNWT-38	23821935	0.5	Ø9.0	Ø4.5	5000
GNWT-39	23821936	0.5	Ø9.0	Ø6.1	5000
GNWT-40	23821937	0.5	Ø10.0	Ø3.1	5000
GNWT-41	23821938	0.5	Ø10.0	Ø4.1	5000
GNWT-42	23821939	0.5	10.0	Ø5.1	5000
GNWT-43	23821940	0.5	Ø10.0	Ø5.2	5000
GNWT-44	23821941	0.5	Ø10.0	Ø5.5	5000
GNWT-45	23821942	0.5	Ø10.0	Ø6.1	5000
GNWT-46	23821943	0.5	Ø10.0	Ø6.4	5000
GNWT-47	23821944	0.5	Ø10.4	Ø7.2	5000
GNWT-48	23821945	0.5	Ø10.5	Ø6.6	5000
GNWT-49	23821946	0.5	Ø10.8	Ø7.2	5000
GNWT-50	23821947	0.5	Ø11.0	Ø5.0	5000
GNWT-51	23821948	0.5	Ø11.6	Ø7.6	5000
GNWT-52	23821949	0.5	Ø12.0	Ø3.6	5000
GNWT-53	23821950	0.5	Ø12.0	Ø5.2	5000
GNWT-54	23821951	0.5	Ø12.0	Ø6.0	5000
GNWT-55	23821952	0.5	Ø12.0	Ø7.3	5000
GNWT-56	23821953	0.5	Ø12.0	Ø8.0	5000
GNWT-58	23821954	0.5	Ø13.0	Ø6.5	5000
GNWT-59	23821955	0.5	Ø13.0	Ø7.95	5000
GNWT-60	23821956	0.5	Ø13.0	Ø8.0	5000
GNWT-99	23821957	0.5	Ø9.1	Ø4.0	5000

Material: NYLON 6
Farbe: NATUR OTHER MATERIAL&THICKNESS AVAILABLE FOR OPTIONAL REQUEST

Reference GNWT-01
