Material: PC (UL)
Flame retardancy class: 94V-2
Material: POM
Flame retardancy class: 94HB
Colour: BLACK TORQUE VALUE CAN BE CUSTOMISED TO CUSTOMERS’ REQUIREMENTS
Enables smooth mechanical movement. Protects sensitive electronics and extends service life by dampening the closing speed of the lid and flap. Prevents noise during movement. High-quality silicone oil seal using ultrasonic technology, stable torque. In combination with a push-lock mechanism to enhance the product’s appeal. Customised torque available to customer specifications. Access flaps for domestic appliances such as TVs, video recorders, CD players, etc. Suitable for car ashtrays and cup holders. Can be used for drawers, sliding doors, waste bins and small furniture flaps.
| Catalogue No. | Item No. | PITCH DIAMETER | MODULE | NUMBER OF TEETH | PRESSURE ANGLE | TORQUE gf-cm | PACKAGE SIZE |
| Gwithershin | 21800100 | clockwise | |||||
| GPG-45-380 | 21800101 | Ø8.8 | 0.8 | 11 | 20° | 380 | 140 |
| GPG-45-700 | 21800102 | Ø8.8 | 0.8 | 11 | 20° | 700 | 200 |
- Material
- PC (UL)
POM - Brandschutzklasse
- 94HB
94V-2 - Farbe
- SCHWARZ TORQUE VALUE CAN BE CUSTOMIZED PER CUSTOMERS' DEMAND
